Z8532NFR-16P | 32CH, 16 Port PoE NVR

• Model: Z8532NFR

SYSTEM

• Processor: Multi-core Embedded Processor
• Operating System:?Embedded Linux

IVA ALARM

• Local IVA Functions: Target Counting, Object Detection, Intrusion, Tripwire
• Regular Detection:?Motion Detection / Video Tampering / Video Loss

I/O PORT AND STORAGE

• Network Interface:?1 RJ-45 port (10/100Mbps)
• USB:?2*USB 2.0
• HDMI:?1 * 4K HDMI
• VGA:?1 * VGA
• Alarm Input:?N/A
• Alarm Output:?N/A
• HDD:?2 SATA, up to 8TB capacity for each HDD
• RAID:?N/A

PLAYBACK AND BACKUP

• Playback Channel:?16
• Search Mode:?IVA Search / Time / Motion Detection
• Playback Function:?Play, Stop, Play forward, Play backward, 30 seconds forward, 30 seconds backward, Fast play, Slow play, Single frame play, Hide/Show the time bar, Backup, Snapshot, Full screen
• Backup Mode:?USB device / Network

VIDEO / AUDIO

• Max. IPC Input: 32
• Audio Compression:?G.711a
• Two-way Talk:?N/A

RECORDING

• Video Compression:?H.265+ / H.265 / H.264+ / H.264
• Recording Resolution:?8MP / 5MP / 3MP / 1080P / 960P / 720P
• Incoming Bandwidth:?80Mbps
• Bitrate:?16K – 8Mbps
• Record Mode:?Manual / External Alarm / Motion / Scheduled / IVA Alarm

NETWORK

• Network Protocol:?TCP/IP, HTTP, DDNS, SMTP (SSL), DHCP, PPPoE, UPnP, NTP, P2P
• Max. Online Users:?5
• Mobile Application:?AntarView Pro
• Interoperability:?Onvif Profile S, SDK
• Power Supply:?DC12V 3A
• Consumption:?? 20W (Without HDD)

GENERAL

• Working Temperature:?-10? ~ +55?
• Working Humidity:?10 ~ 90%
• Dimensions:?325mm * 246mm * 50mm
• Net Weight:?3KG
• Gross Weight:?3.5KG

ORDERING INFORMATION

• Type: PoE NVR
• Part Number: Z8516NFR
• Description: 32 channel 2 SATA NVR
