Z8564NHR
- H.265+/H.265/H.264 decoding
- Support 64-channel 4K IP cameras input
- Support 16 channels of real-time playback synchronously
- HDMI output up to 4K high definition
- Intelligent video analytics functions (up to IPC)
- DHCP, DNS, DDNS, NTP, UPNP, RTSP, etc.
- Support multiple web browsers login
- P2P cloud service supported
- ONVIF Profile S compatible
15
People watching this product now!
Description
| Model | Z8564NHR | |
| System | ||
| Main Processor | Multi-core embedded processor | |
| Operating System | Embedded LINUX | |
| Video and Audio | ||
| Max IPC Input | 64CH | |
| Two-way Talk | Support | |
| Audio Compression | G.711u | |
| Live View | ||
| Display Split | 1/4/6/8/9/16/36/64 CH | |
| Resolution | 8MP(3840*2160) / 5MP(2592*1944) / 2MP(1920*1080) / 1.3MP(1280*1024) / 1Mp(1280*720) / D1(1024*768) | |
| Live View Capability | 36CH@D1(25/30fps) | |
| Recording | ||
| Video Compression | H.265+ / H.265 / H.264 | |
| Recording Resolution | 8MP/5MP/4MP/3MP/1080P/960P/720P/D1 | |
| Max. Decoding Capability | 36CH@D1(25/30fps) | |
| Incoming Bandwidth | 512 Mbps | |
| Bit Rate | Main Stream: 256Kbps ~ 8192Kbps Sub Stream: 50Kbps ~ 700Kbps | |
| Record Mode | Schedule, Manual, Motion Detection, IVA Events Alarm | |
| Record Interval | 1 ~ 120 min (default: 60 min), Pre-record: 1 ~ 30 sec, Post-record: 10 ~ 300 sec | |
| Playback and Backup | ||
| Playback Channel | 16CH | |
| Search Mode | Time/ Date, Alarm Types, IVA Search, Face Retrieval | |
| Playback Function | Play, Stop, Play Forward, Play Backward, 30 Seconds Forward, 30 Seconds Backward, Fast?Play,?Slow?Play,?Single?Frame?Play,?Hide/Show?Time?Bar,?Backup,?Snapshot,?Full?Screen | |
| Backup Mode | USB Device / Network Remote | |
| IVA Alarm | ||
| Local IVA Functions | Line?Crossing?/?Target?Counting?/?Object?Left/Lost?/?Intrusion?/?Scene?change?/?VQD | |
| Regular Detection | Motion Detection / Video Shelter / Video Loss | |
| AI Search | Support search target video by multiple intelligent conditions | |
| Network | ||
| Network Protocol | TCP/IP, HTTP, DDNS, SMTP(SSL), DHCP, PPPoE, UPnP, NTP, P2P | |
| Max. Online User | 5 | |
| Web Browser | Internet Explorer | |
| Operation System | Windows | |
| Management Platform | AntarVis 2.0 (VMS) | |
| Mobile Application | AntarView Pro (iOS & Android) | |
| P2P Cloud Service | Support | |
| Interoperability | ONVIF Profile S, SDK, CGI, API | |
| Storage & Auxiliary Interface | ||
| SATA Ports | 9 SATA Ports, up to 8 TB capacity | |
| eSATA | N/A | |
| Raid 0/1/5/6/10 | Support | |
| HDMI | 1*HDMI (4K) | |
| VGA | 1920*1080/60Hz,1280*1024/60Hz | |
| Network Interface | 1 RJ-45 Port (100Mbps) | |
| PoE Ports | N/A | |
| USB | 1*USB 2.0,?1*USB 3.0 | |
| Audio Input/Output | 1/1 | |
| Alarm Input/Output | 4/1 | |
| RS-485 | Support | |
| Power | ||
| Power Supply | AC100~240V, 47Hz~63Hz | |
| Power Consumption | 35W (Without HDD) | |
| General | ||
| Casing | 2U | |
| Working Temperature | -10?C ~ 55?C / 14?F ~ 131?F | |
| Working Humidity | 10% ~ 90% | |
| Dimensions (L*W*H) | 412 * 430 * 87 (mm) | |
| Net Weight | 7kg (without HDD) | |
| Gross Weight | 7.5kg (without HDD) | |
